Above on the page there're some Service PDF Manuals, Spare Parts Catalogs, Electric Wiring Diagrams & Fault Codes DTC for TEREX Articulated & Rigid Trucks.

Terex also produces truck cranes.

The Terex TA400 is a heavy-duty 6x6 articulated truck designed to haul a wide range of loads in gravel, sand pits and road construction sites.

Designed to operate even in harsh environments, this vehicle is one of the performance leaders in its class.

The Terex TA400 truck has an overall length of 11,055 mm and has a 2,990 mm gap between the front and middle axles (another 1,950 mm is added to the base of the rear bogie).

The width and overall height reach 3,360 mm and 3,945 mm, respectively, and its minimum ground clearance is an impressive 605 mm.

When equipped, the dump truck weighs 30,820 kg, and is capable of taking up to 38,000 kg of cargo on board.

The gross vehicle weight does not exceed 68,820 kg, of which 17,620 kg rests on the front axle, and 51,200 kg on the rear.

By default, the Terex TA400 truck is equipped with a 5658 mm long and 3130 mm wide dumping platform with a volume of 17.4 cubic meters.

The body of the machine is all-welded, made of increased strength steel, with a dual-slope rear end and two single-stage double-acting lift cylinders.

Terex 33-19 Titan is a 6?4 three-axle mining truck-dump truck designed to transport various kinds of rocks and materials on quarry roads under any climatic conditions.

It was built in a piece copy in 1974, and at the time of its appearance it was the largest and most load-bearing vehicle in the world.

Until 1991, the American giant served in the development, and since 1992 it has been exhibited as an open-air historical exhibit in the Canadian city of Sparwood.

In terms of size, the Titan is a real giant: its length is 20,345 mm, its width reaches 7,818 mm, and its height fits into 6,883 mm.

From the front to the middle axle, the dump truck has a gap of 6,706 mm, it has another 4,826 mm at the base of the rear bogie, and its ground clearance is 750 mm.

In curb condition, the Terex 33-19 Titan truck weighs 235 tons, and its carrying capacity is an impressive 350 tons.

The vehicle's tipper platform is 11,240 mm long and 7,569 mm wide.
