The Chinese company Zhejiang Hangcha Engineering Machinery., Ltd began production of its heaviest forklift trucks in 2007.

For forklifts HC of the R series with a load capacity of 14 and 16 tons, the loading center  is 1200 mm.

HC Hangcha designers made 14 and 16 ton forklift trucks with a loading center of 1200 mm.

If at least one of the horizontal dimensions of the load does not exceed 2400 mm, the forklift capacity corresponds to the nominal one.

A 16-ton HC can lift a structure weighing 16 tons with the smallest horizontal dimension of 2400 mm by 5 meters.

The responsibility resting on the operator of a large tonnage truck is as great as the load on the forks of his forklift.

It is enough to imagine the mass of the cargo, its cost and the consequences of the fact that the operator "somehow did not see something."

Modern closed cabins with panoramic windows speak of the attention that the world's leading manufacturers (Kalmar, Komatsu, Toyota, etc.) pay to the view.

Exactly the same cabs are installed on 14 and 16 ton HC Hangcha. Panoramic glazing and a heater are standard for them, and this is the first time in China.

The windshield and side windows are joined end-to-end, without vertical pillars.

Racks were abandoned because they impair visibility.

The area of the windshield has been enlarged so that its lower edge is at seat level 3.

Therefore, the entire front hemisphere is visible as well as from an open cockpit.

14 and 16 ton HC forklift trucks are equipped with one of two 6 cylinder CUMMINS diesel engines: 6BTA5.9 (5900 cm3, 138 kW/2300 rpm) or QSB6.7 (6700 cm3, 142 kW/2300 rpm) /min).

It is noteworthy that the QSB6.7 model complies with EURO IIIA / EPA II emission standards.

This diesel engine is currently used on heavy equipment manufactured by JCB, Terex, CVS Ferrari.

With the Cummins QSB6.7 engine, the 16 ton loader accelerates to 27 km/h without load and up to 22.5 km/h with a full load.

With a pulling force of 130 kN (fully loaded), it is able to drive up slopes of 25%.
